Actual Product May Vary From Image

012794 DOD

Name: 012794 DOD
Brand: Dodge
SKU: 012794 DOD
Availability: OutOfStock

PX120 TL COMPLETE COUPLING RSB

Manufacturer: Dodge

Manufacturer part number: 012794

Estimated dates are contingent upon manufacturer stock.

Please login to see accurate availability

Price on Request

Qty:

Product Details

Angular Misalignment:	4.0000
Angular Misalignment (Unit):	DEGREE
Axial Misalignment:	0.3125
Axial Misalignment (Unit):	INCH
Bore Diameter (Maximum):	3.2500
Bore Diameter (Maximum) (Unit):	INCH
Bore Diameter (Minimum):	0.8750
Bore Diameter (Minimum) (Unit):	INCH
Bushing Size:	3020
Bushing Type:	Taper-Lock
Coupling Component:	Assembly
Coupling Size:	PX120
Coupling Style:	Tire
Coupling Type:	Elastomeric
Element Material:	Natural Rubber
Flange Material:	Cast Iron
Horsepower Per 100 Rat:	20.0000
Horsepower Per 100 Rat (Unit):	HORSEPOWER
Lubrication:	None
Maximum Speed:	2100
Maximum Speed (Unit):	RPM
Maximum Temperature Rating:	180.0000
Maximum Temperature Rating (Unit):	FAHRENHEIT
Minimum Temperature Rating:	-45.0000
Minimum Temperature Rating (Unit):	FAHRENHEIT
Parallel Misalignment:	0.1250
Parallel Misalignment (Unit):	INCH
Rated Torque:	12605.0000
Rated Torque (Unit):	INCH_POUND
Shaft Attachment:	Bushed
