0230-01400 HUB

Name: 0230-01400 HUB
Brand: Hub City
SKU: 0230-01400 HUB
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturers:

Hub City , Hub City , Hub City

Manufacturer part number:

0230-01400

CBT Inventory

Vendor Inventory

Availability:

1-2 weeks.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Hub City®

Type

Right Angle Single Reduction Style A

Description

Hub City® PowerCubeX® Worm Gear Reducer, Right Angle Single Reduction Style A, Series: 180PCX, 7.5:1 Gear Ratio, 2.05 hp Input, Shaft Input, Hollow Bore Output, 0.625 in Dia x 1.76 in L Input, 1 in Dia Output, 233 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 468 in-lb Output, 1-3/4 in Centre Distance, 3/16 x 3/32 in Input, 1/4 x 1/8 in Output Keyway, 84.7 % Efficiency, Conventional Oil Lubrication, Cast Iron, 4.81 in W x 5 in H

Application

Conveyors and Conveying Equipment, Printing Equipment, Agriculture, Food Processing, Bottling Equipment, Grain Handling, Packaging Machinery, Cement and Asphalt

Standards

AGMA Class 1

Features

Modular design
Universal mounting dimensions
Increased thermal capacity and increased efficiency
Alloy shafting
FKM seals

Specifications

Centre Distance:	1-3/4 in
Dimensions:	4.81 in W x 5 in H
Efficiency:	84.7 %
Gear Ratio:	7.5:1
Horsepower:	2.05 hp Input
Input Maximum Speed:	1750 rpm
Input Size:	0.625 in Dia x 1.76 in L
Input Type:	Shaft
Keyway Size:	3/16 x 3/32 in Input, 1/4 x 1/8 in Output
Lubrication Type:	Conventional Oil
Material:	Cast Iron
Output Maximum Speed:	233 rpm
Output Size:	1 in Dia
Output Type:	Hollow Bore
Series:	180PCX
Torque Rating:	468 in-lb Output
