Actual Product May Vary From Image

023025 DOD

Name: 023025 DOD
Brand: Dodge
SKU: 023025 DOD
Price: 684.71 USD
Availability: OutOfStock

P4B-E-208R

Manufacturer: Dodge

Manufacturer part number: 023025

Estimated dates are contingent upon manufacturer stock.

Please login to see accurate availability

$684.71

Qty:

Product Details

Base to Center Height:	2.7500
Base to Center Height (Unit):	INCH
Bearing Type:	Tapered Roller
Bolt Diameter:	0.6250
Bolt Diameter (Unit):	INCH
Bolt to Bolt (Max):	8.6900
Bolt to Bolt (Max) (Unit):	INCH
Bolt to Bolt (Min):	8.3100
Bolt to Bolt (Min) (Unit):	INCH
Bolt Width:	1.8800
Bolt Width (Unit):	INCH
Bore Length:	4.0000
Bore Length (Unit):	INCH
Expansion Capability:	Non-Expansion (Fixed)
Greasable:	Yes
Grease Name:	MobilGrease XHP222
Housing Construction:	Solid
Housing Dimensional Standard:	Type E
Housing Material:	Cast Iron
Housing Type:	Four-Bolt Pillow Block
Insert Material:	Steel
Lubrication:	Grease
Maximum Speed:	2420
Maximum Speed (Unit):	RPM
Seal Type:	Triple-Lip Contact
Sensor Ready:	Yes
Shaft Attachment:	Setscrew
Shaft Diameter:	2.5000
Shaft Diameter (Unit):	INCH
Static Load Capacity:	54000
Static Load Capacity (Unit):	POUND_FORCE
Take-Up Frame Size:	CP-502,HD-200
