Actual Product May Vary From Image

0314002.VXP LIT

Name: 0314002.VXP LIT
Brand: Littelfuse
SKU: 0314002.VXP LIT
Price: 4.22 USD
Availability: InStock

Littelfuse® POWR-GARD® 314002P Fast Acting Cartridge Fuse, 2 A, 250 VAC, 10 kA Interrupt, Class: K5, Cartridge Body

Manufacturer: Littelfuse

Manufacturer part number: 314002P

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
10	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CBT - LOUISVILLE
0	0
Loading...

$4.22

Qty:

Product Details

Brand Name

Littelfuse®

Type

Fast Acting

Description

For over 85 years Littelfuse® has been providing fuses to the electrical market. You can continue to count on our manufacturing and supply chain processes to deliver high quality fuses when you need them. At Littelfuse® we leverage our global reach to stay on top of the latest applications and standards. Whether your circuit protection needs are focused on OEM, MRO or construction, we are committed to being your circuit protection partner and appreciate your business.

Littelfuse® POWR-GARD® Cartridge Fuse, Fast Acting, Series: 314, Non-Indicating, 2 A, 250 VAC, 10 kA Interrupt, Class: K5, 1 hr, 4 hr, 15 s Response, Ferrule Terminal, Holder Mounting, Cartridge Body, Ceramic, 1/4 in Dia x 1-1/4 in L Body

Application

For supplementary protection in appliance or utilization equipment to provide individual protection for components or internal circuits

Standards

Standard 248-6 UL File No. E10480 | CSA 29862 | PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer

Features

3AB Fast-Acting fuse with ceramic body construction permits higher interrupting ratings and voltage ratings
Ideal for applications where high current loads are expected
Nickel plated brass cap
Lead-free
-55 to 125 deg C of operating temperature
10 kA at 125 VDC interrupting rating
1 hr maximum at 135%, 4 hrs maximum at 100%, 15 sec at 200% of response time

Specifications

Amperage Rating:	2 A
Body Size:	1/4 in Dia x 1-1/4 in L
Body Type:	Cartridge
Class:	K5
Country of Origin:	CA
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	10 kA
Material:	Ceramic
Mounting Type:	Holder
Response Time:	1 hr, 4 hr, 15 s
Series:	314
Terminal Type:	Ferrule
Voltage Rating:	250 VAC
