Picture of 120E25H MSG
Actual Product May Vary From Image

120E25H MSG

Martin 120E25H Type B Single Strand Solid Bushed Roller Chain Sprocket With Hardened Teeth, 0.875 to 3.313 in Dia Bore, 12.774 in OD, #120 Chain, 25 Teeth, 1-1/2 in Pitch, Steel
Manufacturer: Martin Sprocket & Gear
Manufacturer part number: 120E25H
Availability: Ships in 2-4 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$516.49

Product Details

Brand Name

Martin

Type

Type B Single Strand Solid Bushed

Description

Martin saber tooth sprockets have hardened teeth, which provide longer chain and sprocket life. The hardened teeth on the smaller sprocket of a roller chain drive are recommended if the drive ratio is four to one or greater if the smaller sprocket has 24 teeth or less and is running at a speed of over 600 rpm.
Martin Roller Chain Sprocket, Type B Single Strand Solid Bushed, 0.875 to 3.313 in Bore, 12.774 in OD, #120 Chain, 25 Teeth, 1-1/2 in Pitch, 11.9681 in Pitch Diameter, 6-1/4 in Diameter Hub, 1/2-13 UNC Screw, 1.62 in Length Through Bore, QD® E Bushing, Steel

Standards

ANSI Specified | B29.1 - 1975

Features

  • Precise machining and processes ensure consistent finish and high quality
  • Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
  • Bores are concentric to pitch line, minimizing run out
  • Interchangeable with other manufacturer's QD® bushings
  • Stocked heat treat
  • Manufactured of high carbon steel

Specifications

Bore Diameter:0.875 to 3.313 in
Bushing Type:QD® E
Chain Size:#120
Hub Diameter:6-1/4 in
Length Through Bore:1.62 in
Material:Steel
Number of Teeth:25
Outside Diameter:12.774 in
Pitch:1-1/2 in
Pitch Diameter:11.9681 in
Screw Size:1/2-13 UNC
