128711 DOD

Name: 128711 DOD
Brand: Dodge
SKU: 128711 DOD
Price: 208.20 USD
Availability: OutOfStock

Actual Product May Vary From Image

Manufacturer:

Manufacturer part number:

128711

product.name:

128711 DOD

CBT Inventory

Vendor Inventory

Availability:

Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

$208.20 / EA

Description

Ball Bearing Series:	209 Series
Base to Center Height:	2.1300
Base to Center Height (Unit):	INCH
Bearing Type:	Ball
Bolt Diameter:	0.5000
Bolt Diameter (Unit):	INCH
Bolt to Bolt (Max):	6.1900
Bolt to Bolt (Max) (Unit):	INCH
Bolt to Bolt (Min):	5.5000
Bolt to Bolt (Min) (Unit):	INCH
Bore Length:	2.0100
Bore Length (Unit):	INCH
Dynamic Load Capacity:	7891
Dynamic Load Capacity (Unit):	POUND_FORCE
Expansion Capability:	Non-Expansion (Fixed)
Greasable:	Yes
Grease Name:	Unirex N2
Housing Construction:	Solid
Housing Material:	Cast Iron
Housing Type:	Two-Bolt Pillow Block
Insert Material:	Steel
Lubrication:	Grease
Maximum Speed:	5000
Maximum Speed (Unit):	RPM
Seal Type:	Single-Lip Contact
Sensor Ready:	Adapter Required
Shaft Attachment:	Clamp Collar
Shaft Diameter:	1.6250
Shaft Diameter (Unit):	INCH
Standoff Housing:	No
Static Load Capacity:	4906
Static Load Capacity (Unit):	POUND_FORCE
Suitable for High Temperature:	No
Suitable For Washdown:	No
Take-Up Frame Size:	LD-20,TS-250
