Actual Product May Vary From Image

14W47-W WOO

Name: 14W47-W WOO
Brand: Molex/Woodhead
SKU: 14W47-W WOO
Price: 365.97 USD
Availability: OutOfStock

Woodhead® 14W47-W 130154 Male/Female Standard Molded W Cordset, 15 A at 125 VAC, 3 ft L Cord

Manufacturer: Molex/Woodhead

Manufacturer part number: 14W47-W

Availability: Expected Leadtime 12 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$365.97

Qty:

Product Details

Brand Name

Woodhead®

Type

Male/Female Standard

Description

Woodhead® Molded W Cordset, Male/Female Standard, Series: 130154, 15 A at 125 VAC Electrical Rating, 3 ft Cord Length, 12 AWG Conductor, Triple Receptacle, IP67 Enclosure, -40 to 75 deg C, Rubber, Yellow

Application

For closure caps and additional support with strain relief grips

Standards

UL E38085 | CSA LL52750

Features

F2 body 1/2 in cord grip
SOW cord
Multiple seal plug/connector interface keeps out contaminants, resists vapor and water from high pressure wash down upto 1000 psi
Color coded 1/4 in terminal screws preset in open position, ready to wire
Wire screw terminals are tri-drive to be used with straight blade, Phillips® and square drive screw drivers
Floating blade construction provides self-alignment and a better mechanical and electrical connection minimizing wear and heat generation
Transparent wiring guide to verify all wire strands are in place before securing wire
Captive, tri-drive head, stainless steel, speed screw provides easy assembly and long life
Three piece strain relief seals cord without damaging the cord

Specifications

Color:	Yellow
Conductor Size:	12 AWG
Cord Length:	3 ft
Country of Origin:	MX
Electrical Ratings:	15 A at 125 VAC
Enclosure:	IP67
Material:	Rubber
Receptacle Type:	Triple
Series:	130154
Temperature Rating:	-40 to 75 deg C
