Picture of 16362-IGI LEV
Actual Product May Vary From Image

16362-IGI LEV

Leviton® Decora® Plus 16362-IGI 1-Phase Duplex Extra Heavy Duty Isolated Grounding Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Ivory
Manufacturer: Leviton Manufacturing
Manufacturer part number: 16362-IGI
Availability: Ships in 5-7 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
Price on Request

Product Details

Brand Name

Leviton®

Type

1-Phase Duplex Extra Heavy Duty Isolated Grounding

Alternate Supplier #

Grainger - 25MN74

Description

All Leviton® hospital grade receptacles undergo the most stringent UL testing to assure continuous, safe operation in any application requiring high abuse tolerance, including health care facilities, manufacturing plants and schools.
Leviton® Decora® Plus Straight Blade Receptacle, 1-Phase Duplex Extra Heavy Duty Isolated Grounding, 125 VAC, 20 A, 1 hp, 2 Pole, 3 Wires, NEMA 5-20R NEMA Rating, Commercial Grade, -40 to 60 deg C, Back/Side Wire Terminal, Nylon, Ivory, 46 in H x 1.52 in W x 1.14 in D Dimensions

Standards

NEMA WD1/WD6 | ANSI C73 | NOM 057 | CSA C22.2 No. 42 File No. 152105 | UL 498HG File No. E13399 | UL94 V-2 Flammability Rating

Features

  • Durable thermoplastic face in an array of contemporary colors
  • Receptacles have a locked-in mounting strap with a self-grounding clip riveted to the strap
  • Hospital grade tamper resistant receptacles include a unique shutter mechanism that opens easily for the insertion of 2 or 3-prong plugs while preventing entry by other small objects into either outlet slot
  • Hospital grade isolated ground receptacles protect sensitive electronic equipment and eliminate electromagnetic interference by providing a separate path to ground
  • Power Indication™ meets UL 498 hospital grade identification requirements

Specifications

Amperage Rating:20 A
Color:Ivory
Dimensions:46 in H x 1.52 in W x 1.14 in D
Grade:Commercial
Horsepower:1 hp
Material:Nylon
NEMA Rating:NEMA 5-20R
Number of Poles:2
Number of Wires:3
Temperature Rating:-40 to 60 deg C
Terminal Type:Back/Side Wire
Voltage Rating:125 VAC
