Home / 2050H17 BRN

2050H17 BRN

Product Details

Manufacturer:
Manufacturer part number:
1173442
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Ships in 3-5 days.
Estimated dates are contingent upon manufacturer stock.
Price on Request

Description

Brand Name

Browning®

Type

Single Strand

Description

Browning® stock sprockets for extended pitch chain have larger pitch diameters than standard roller chain sprockets as extended pitch chain will not operate satisfactorily on standard roller chain sprockets with less than 24 teeth. They will normally operate satisfactorily on standard roller chain sprockets with 24 or more teeth. Sprockets for extended pitch chain with large rollers are available on special order.
Browning® Roller Chain Sprocket, Single Strand, 3/8 to 1-1/2 in Bore Dia, 3.71 in Outside Dia, 2050 Chain, 17 Teeth, 1-1/4 in Pitch, 3.4603 in, 2-1/2 in Hub Dia, 1-1/4 in Length Through Bore, Type H Split Taper Bushing, Steel

Application

Aggregate and Cement, Agriculture, Forestry, Minerals and Mining and Pulp and Paper Industries

Features

  • Easy installation and removal
  • Hardened teeth at no extra cost drive sizes up to 30 teeth on 35 through 160 chain
  • External key have higher torque capacity, aligns bolt holes
  • Provides key to key drive
  • Solid flange true concentricity, easy installation
  • Longer barrel have better support on the shaft

Specifications

Bore Diameter:3/8 to 1-1/2 in
Bushing Type:Type H Split Taper
Chain Size:2050
Country of Origin:CN
Hub Diameter:2-1/2 in
Length Through Bore:1-1/4 in
Material:Steel
Number of Teeth:17
Outside Diameter:3.71 in
Pitch:1-1/4 in
Pitch Diameter:3.4603 in
