21312EJW33C3 TKN

Product Details

Manufacturer:
Manufacturer part number:
21312EJW33C3
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Ships in 3-5 days.
Estimated dates are contingent upon manufacturer stock.
Price on Request

Description

Brand Name

Timken

Description

Misalignment, contamination, high-temperatures, even extreme speeds or critical stresses can present extra challenges when managing high radial loads. Timken® spherical roller bearings can handle it all, with innovations designed to extend bearing life and boost reliability. Timken® spherical roller bearings with hardened steel cages deliver greater fatigue strength, increased wear-resistance and tougher protection against shock and acceleration.
Timken®, 21312EJW33C3, Spherical Roller Bearing, Cylindrical Bore Type EJ, Series: 213, 60 mm Bore, 130 mm OD, 2 Rows, 31 mm Width, 50500 lb Dynamic/49200 lb Static Load, Steel Bearing, 4200 rpm Grease/5100 rpm Oil Maximum, -65 to 392 deg F

Features

  • Enhanced surface finishes
  • Optimized internal geometry
  • Industry-leading load ratings
  • Nitride hardened steel cage with face slots |(W33) Standard lubrication holes and groove in outer ring

Specifications

Bearing Material:Steel
Bearing Type:Spherical Roller Bearings
Bore Type:Straight
Cage (Retainer) Type:Design Style - EJ
Cage Material:Steel Cage
Component (I/R; O/R assembly):Assembly
Dynamic Load Rating:50500
Fillet Radius - Inch:0.08
Fillet Radius - Millimeter:2
Inner Race Width (in):1.2205
Inner Race Width (mm):31
Internal Clearance:C3
Load Rating UOM:LB
Lubrication Hole/Groove:yes
Manufacturer Produt Page Link:https://www.timken.com/products/timken-engineered-bearings/spherical/
Material - Rolling Elements:Roller
Maximum Operating RPM (Grease):4200
Maximum Operating RPM (Oil):5100
Outer Diameter (in):5.118
Outer Diameter (mm):130
Outer Diameter Type:Straight
Outer Race Width (in):1.2205
Outer Race Width (mm):31
Overall Width (in):1.221
Overall Width (mm):31
Precision class:P0
Relubricatable:yes
Rolling Element:Spherical
Row Type:Double
Self Aligning:Yes
Series:213
Shaft Size (in):2.362
Shaft Size (mm):60
Snap Ring:no
Static Load Rating:49200
