224WD BR TKN

Bearings in the 200 series bearings feature a close dimensional balance between bore, outside diameter and width. These characteristics make them well-suited for a broad range of applications involving light to medium loads combined with relatively high-speeds. Wide-type 200 series rubber seal(W200PP) and mechani-seal(W200KLL) bearings are made with standard bores and outside diameters, but in widths equal to the corresponding sizes of double-row bearings. This series offers a larger support area for shaft and housing contact and extra space for lubricant.

Fafnir® Radial Deep Groove Ball Bearing, Light Round Bore, Series: 200W, 4.7244 in Bore, 8.4646 in OD, 1 Rows, 1.5748 in Width, Single Shield Closure, 50000 lb Dynamic/41500 lb Static Load, Steel Bearing, Metal Seal, Brass/Bronze Cage, 1790 rpm Maximum, Uncoated
