23222CJW33C3 TKN

Name: 23222CJW33C3 TKN
Brand: Timken
SKU: 23222CJW33C3 TKN
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Timken

Manufacturer part number:

23222EJW33C3

Availability:

Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Timken®

Type

Cylindrical Bore Type EJ

Description

Misalignment, contamination, high-temperatures, even extreme speeds or critical stresses can present extra challenges when managing high radial loads. Timken® spherical roller bearings can handle it all, with innovations designed to extend bearing life and boost reliability. Timken® spherical roller bearings with hardened steel cages deliver greater fatigue strength, increased wear-resistance and tougher protection against shock and acceleration.

Timken®, 23222EJW33C3, Spherical Roller Bearing, Cylindrical Bore Type EJ, Series: 232, 110 mm Bore, 200 mm OD, 2 Rows, 69.8 mm Width, 159000 lb Dynamic/199000 lb Static Load, Steel Bearing, 2000 rpm Grease/2300 rpm Oil Maximum, -65 to 392 deg F

Application

Continuous Casters, Metal Mills, Crushers, Vibrating Screens, Excavation/Loading, Miners, Bulk Material Handling, Conveying, Oil and Gas, Mud Pumps and Pulp and Paper

Features

Run at consistently lower temperatures than same-size competitive bearings for greater reliability
Optimized internal geometries deliver the highest load and speed ratings in the industry
Spherical bearings are designed to manage high radial loads even when misalignment, poor lubrication, contamination, extreme speeds or critical application stresses are present
High-performance stamped nitrided steel cage
Standard lubrication holes and groove in outer-ring
C3 bearing radial internal clearance (RIC) greater than norma

Specifications

Bearing Material:	Steel
Bore Diameter:	110 mm
Cage Material:	Steel
Load Capacity:	159000 lb Dynamic/199000 lb Static
Maximum Speed:	2000 rpm Grease/2300 rpm Oil
Number of Rows:	2
Outside Diameter:	200 mm
Series:	232
Temperature Rating:	-65 to 392 deg F
Width:	69.8 mm
