23Q30R14 DOD

Name: 23Q30R14 DOD
Brand: Dodge
SKU: 23Q30R14 DOD
Price: 1,148.54 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Dodge

Manufacturer part number:

23Q30R14

product.name:

23Q30R14 DOD

CBT Inventory

Vendor Inventory

Availability:

Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

$1,148.54 / EA

Description

Specifications

Base to Output Center Height:	2.5000
Base to Output Center Height (Unit):	INCH
Case Size:	23
Center Distance:	2.3100
Center Distance (Unit):	INCH
Center to End of Shaft Distance:	5.1400
Center to End of Shaft Distance (Unit):	INCH
Horsepower Rating Input:	1.4200
Horsepower Rating Input (Unit):	HORSEPOWER
Horsepower Rating Output:	1.1100
Horsepower Rating Output (Unit):	HORSEPOWER
Housing Material:	Cast Iron
Input Style:	Quill
Lubrication:	PAG, Standard Temperature
Motor Compatibility:	NEMA Motor, 140TC Frame
Mounting Bolt Pattern Length:	5.0000
Mounting Bolt Pattern Length (Unit):	INCH
Mounting Bolt Pattern Width:	2.8800
Mounting Bolt Pattern Width (Unit):	INCH
Nominal Ratio:	30.0000
Output Shaft:	Right (Solid B)
Output Shaft Center to Input Motor Mounting Face Distance:	5.4600
Output Shaft Center to Input Motor Mounting Face Distance (Unit):	INCH
Output Style:	Right
Overhung Load:	1610
Overhung Load (Unit):	POUND_FORCE
Paint Type:	Standard
Rated Torque Output:	1201
Rated Torque Output (Unit):	INCH_POUND
Seal Type:	Single-Lip Contact
Shaft Diameter Output:	1.1250
Shaft Diameter Output (Unit):	INCH
Shaft Length Output:	2.1800
Shaft Length Output (Unit):	INCH
Suitable For Washdown:	No
Thermal Horsepower Rating:	2.0600
Thermal Horsepower Rating (Unit):	HORSEPOWER

Resources

Installation
