241/600-B-K30-MB FAG

Name: 241/600-B-K30-MB FAG
Brand: INA
SKU: 241/600-B-K30-MB FAG
Availability: OutOfStock

FAG 241/600-B-K30-MB Tapered Bore Spherical Roller Bearing, 600 mm Dia Bore, 980 mm OD, 2 Rows, 375 mm W, 26000 kN Load

Manufacturer: INA

Manufacturer part number: 241/600-B-K30-MB

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

FAG

Type

Tapered Bore

Description

Spherical roller bearings are a special rolling bearing design whose inner ring runs inside the outer ring on two rows of rollers. The bearings have an angular adjustment of up to 2 deg and are not only designed for high load carrying capacity but can also compensate misalignments.

FAG Spherical Roller Bearing, Tapered Bore, Series: 241, 600 mm Bore, 980 mm OD, 2 Rows, 375 mm Width, Open Closure, 26000 kN Load, Solid Brass Cage, 450 rpm Maximum, -30 to 200 deg C

Features

Spherical roller bearings are suitable where rearing arrangements are subjected to high and very high radial loads
Relatively high axial loads occur on one or both sides, in addition to high radial forces
Dynamic or static misalignments of the shaft relative to the housing, or deflections of the shaft, must be freely compensated by the bearing
High shock type loads must be supported dynamically
Locating bearings with a very high load carrying capacity are required
Two brass cages, guidance on inner ring, inner ring with two lateral retaining ribs and one central rib
1:30 tapered bore
Rigid central rib on inner ring
11600 kN dynamic/26000 kN static

Specifications

Bore Diameter:	600 mm
Cage Material:	Solid Brass
Closure Type:	Open
Country of Origin:	DE
Load Capacity:	26000 kN
Maximum Speed:	450 rpm
Number of Rows:	2
Outside Diameter:	980 mm
Series:	241
Temperature Rating:	-30 to 200 deg C
Width:	375 mm
