2MMV9322HXVV DUL FS637 TKN

Name: 2MMV9322HXVV DUL FS637 TKN
Brand: Timken
SKU: 2MMV9322HXVV DUL FS637 TKN
Price: 10,249.36 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Timken

Manufacturer part number:

2MMV9322HXVVDULFS637

CBT Inventory

Vendor Inventory

Availability:

Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

$10,249.36 / EA

Description

Brand Name

Timken®

Type

Light Duty

Description

2MMV-HX VV possess all of the high-speed advantages of the HX but with true high-speed seals. These bearing seals protect lubricant from outside contaminants while ensuring internal lubricant retention, extending service life significantly.

Timken® Super Precision Angular Contact Ball Bearing, Light Duty, Series: 2MMV9300HX, 110 mm Bore, 150 mm OD, 2 Rows, 20 mm Width, 15 deg Contact Angle, Double Seal Closure, 32200 N Dynamic/26400 N Static Load, Phenolic Cage, 10500 rpm Maximum

Application

High Speed Internal Grinding Spindle, Ultra Precision Surface Grinding Spindle, Precision Surface Grinding Spindle, Heavy Duty Precision Boring Spindle, High Speed Precision Boring Head, Ultra Precision Grinding Workhead, Single Bar Machine, Precision Jig Boring Spindle, Super Precision Lathe Headstock, High Speed Motorized Router and Precision Vertical Milling Spindle

Standards

ABMA ABEC 7/9 Certified

Features

Single and double-row ball screw
Very high-speed
High accuracy and stiffness
Low operating temperature
Low noise and vibration
Angular contact low shoulder on both inner and outer-ring
Kluber Isoflex NBU 15 grease lubricant

Specifications

Bore Diameter:	110 mm
Cage Material:	Phenolic
Closure Type:	Double Seal
Contact Angle:	15 deg
Load Capacity:	32200 N Dynamic/26400 N Static
Maximum Speed:	10500 rpm
Number of Rows:	2
Outside Diameter:	150 mm
Series:	2MMV9300HX
Width:	20 mm
