3247FT1 LBB

Name: 3247FT1 LBB
Brand: Rexnord
SKU: 3247FT1 LBB
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Rexnord

Manufacturer part number:

3247FT1

CBT Inventory

Vendor Inventory

Availability:

Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Link-Belt®

Type

Non-Expansion Standard Duty

Description

Flex-Block® sleeve bearings are alignable and self-lubricating. Because the bearing material wears gradually under operation, sudden breakdowns and costly maintenance are minimized. The standard bearing insert materials of oil impregnated porous sintered bronze or self-lubricating graphite are widely used for the extreme applications of modern industry.

Link-Belt® Flex-Block® Flanged Sleeve Bearing Unit, Non-Expansion Standard Duty, Series: 3200, 2-15/16 in Bore, 6 in Bolt Center-to-Center Length, 4-Bolt Square Flange Mounting, 7-3/4 in Overall Length/Diameter, 3-5/16 in Overall Depth, 7-3/4 in Overall Height, Porous Sintered Bronze Bearing, 253 ft-lb Load, 1000 rpm Maximum, 32 to 200 deg F, Powder Coated

Application

Commercial Furnaces, Heat Treatment, Wastewater Management, Dams and Air Handling Industries

Standards

ANSI | ABMA STD 11-1990

Features

Sturdy 1-piece housings with machined mounting surfaces
Component has machined spherical surface for proper seating in housing and for initial mounting alignment
When the component retaining screw is loosened the insert can be rotated 180 deg to utilize unused bearing surface and extend the life of the unit
Cast iron housing
Corrosion-resistant
Oil impregnated sleeve bearing

Specifications

Bearing Material:	Porous Sintered Bronze
Bolt Center-to-Center Length:	6 in
Bore Diameter:	2-15/16 in
Country of Origin:	MX
Finish:	Powder Coated
Flange Mounting Type:	4-Bolt Square
Load Capacity:	253 ft-lb
Maximum Speed:	1000 rpm
Overall Depth:	3-5/16 in
Overall Height:	7-3/4 in
Overall Length/Diameter:	7-3/4 in
Series:	3200
Temperature Rating:	32 to 200 deg F
