Actual Product May Vary From Image

35BS19H X 5/8 BLT

Name: 35BS19H X 5/8 BLT
Brand: Bearings Limited
SKU: 35BS19H X 5/8 BLT
Price: 17.64 USD
Availability: OutOfStock

TRITAN® 35BS19H X 5/8 Standard Bored To Size - Hub Type Hardened Teeth Single Strand Precision Roller Chain Sprocket, 5/8 in Dia Bore, 2.47 in OD, 35 Chain, 19 Teeth, 3/8 in Pitch, Forged Steel

Manufacturer: Bearings Limited

Manufacturer part number: 35BS19H X 5/8

Availability: 1-2 weeks.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$17.64

Qty:

Product Details

Brand Name

TRITAN®

Type

Bored To Size - Hub Type Hardened Teeth

Description

TRITAN® sprockets are made of heavy duty forged steel, never sintered as some others, with black oxide finish for resistance to corrosion and long lasting durability and dependability. Teeth are hardened to provide extra wear life, extending chain life and saving on downtime and replacement cost.

TRITAN® Single Strand Precision Roller Chain Sprocket, Bored To Size - Hub Type Hardened Teeth, Series: Standard, 5/8 in Bore, 2.47 in OD, 35 Chain, 19 Teeth, 3/8 in Pitch, 1/4 in Screw, 3/16 in W Keyway, 3/4 in Length Through Bore, Forged Steel, Black Oxide

Application

Vehicle Transmissions, Conveyor Belts or Other Industrial Machinery and Mechanical Applications

Standards

American Petroleum Institute | ANSI B-29-1 | DIN8196 | JIS1801

Specifications

Bore Diameter:	5/8 in
Chain Size:	35
Finish:	Black Oxide
Keyway Size:	3/16 in W
Length Thru Bore:	3/4 in
Material:	Forged Steel
Number of Teeth:	19
Outside Diameter:	2.47 in
Pitch:	3/8 in
Screw Size:	1/4 in
Series:	Standard
