Picture of 40 DLT HUB 1-3/8 5/16X5/32K LOV
Actual Product May Vary From Image

40 DLT HUB 1-3/8 5/16X5/32K LOV

Lovejoy® 68514439008 Deltaflex Delta Finished Bore Flex Link Coupling Hub With (2) Setscrews, 40 Coupling, 1-3/8 in Dia Bore, 1.34 in L Through Bore, 2.56 in Dia Hub, Ductile Iron
Manufacturer: Lovejoy
Manufacturer part number: 68514439008
Availability: Ships in 2-4 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$179.22

Product Details

Brand Name

Lovejoy®

Type

Delta Finished Bore

Description

Lovejoy® Flex Link Coupling Hub, Delta Finished Bore, Series: Deltaflex, 40 Coupling, 1-3/8 in Bore, 2.56 in Diameter Hub, 1.34 in Hub Length, 5/16 in W x 5/32 in D Keyway, 1.34 in Length Through Bore, 1/4-20 Screw, Ductile Iron, Metallic/Zinc Clear Dichromate Plated

Application

Compressors, Pumps, Fans, Positioning Devices, Indexing Tables, Mixers, Papermill Roll Drives, Drive Line Shafts, Turbine Drives, Wind Tunnels, Cooling Towers and Single Bearing Generator Drives Applications

Standards

ACMA Certified | ECCN EAR99 | EPTDA Approved | FPDA Motion and Control Network Member | Member of Hydraulic Institute | MPTA Standard | NFPA Member | PTDA Approved

Features

  • Maximum misalignment capabilities, with negligible reactionary load, for longer equipment bearing life
  • Operates as smoothly when misaligned as when perfectly aligned
  • No lubrication and no maintenance required
  • Equipment can be visually aligned
  • No special tools are required, which saves on installation time and cost
  • Eliminates premature equipment bearing and seal failure resulting from misalignment forces
  • This means greater equipment productivity
  • Torsionally stiff coupling with no backlash means it is capable of high speed applications, within catalog ratings
  • Provides long-term performance and economy

Specifications

Bore Diameter:1-3/8 in
Country of Origin:US
Coupling Size:40
Finish:Metallic/Zinc Clear Dichromate Plated
Hub Diameter:2.56 in
Hub Length:1.34 in
Keyway Size:5/16 in W x 5/32 in D
Length Through Bore:1.34 in
Material:Ductile Iron
Screw Size:1/4-20
Series:Deltaflex
