Actual Product May Vary From Image

40SH28H MSG

Name: 40SH28H MSG
Brand: Martin Sprocket & Gear
SKU: 40SH28H MSG
Price: 81.26 USD
Availability: OutOfStock

Martin Saber Tooth® 40SH28H QD Bushed Type B Single Pitch Roller Chain Sprocket With Hardened Teeth, 4.738 in OD, #40 Chain, 28 Teeth, 1/2 in Pitch, Steel

Manufacturer: Martin Sprocket & Gear

Manufacturer part number: 40SH28H

Availability: Ships in 2-4 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$81.26

Qty:

Product Details

Brand Name

Martin

Type

QD Bushed Type B

Description

Martin Saber Tooth® sprockets have hardened teeth, which provide longer chain and sprocket life. The hardened teeth on the smaller sprocket of a roller chain drive are recommended if the drive ratio is four to one or greater if the smaller sprocket has 24 teeth or less and is running at a speed of over 600 rpm.

Martin Saber Tooth® Single Pitch Roller Chain Sprocket, QD Bushed Type B, 4.738 in Outside Dia, #40 Chain, 28 Teeth, 1/2 in Pitch, 4.466 in, 3 in Hub Dia, 1-5/16 in Length Through Bore, Type SH QD® Bushing, Steel

Standards

PROP65: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov

Specifications

Bushing Type:	Type SH QD®
Chain Size:	#40
Country of Origin:	US
Hub Diameter:	3 in
Length Through Bore:	1-5/16 in
Material:	Steel
Number of Teeth:	28
Outside Diameter:	4.738 in
Pitch:	1/2 in
Pitch Diameter:	4.466 in
