4105 INA

Name: 4105 INA
Brand: INA
SKU: 4105 INA
Availability: OutOfStock

INA 4105 Axial Deep Groove Ball Bearing, 0.984 in Dia Bore, 1.89 in OD, 1 Rows, 0.669 in W, 5850 lb Dynamic/10340 lb Static Load

Manufacturer: INA

Manufacturer part number: 4105

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

INA

Description

INA Axial Deep Groove Ball Bearing, Series: 41 Series, 0.984 in Bore Dia, 1.89 in Outside Dia, 1 Rows, 0.669 in Width, Separable Face, Single Thrust Direction, 5850 lb Dynamic/10340 lb Static, Steel Bearing, 5000 rpm Maximum

Features

Medium cross section
Grooved race
Angular adjustment facility
Separable axial contact
Static alignment is equal to +/- 3.0 deg
Speed limit shown is for oil lubrication

Specifications

Bearing Material:	Steel
Bore Diameter:	0.984 in
Face Type:	Separable
Load Capacity:	5850 lb Dynamic/10340 lb Static
Maximum Speed:	5000 rpm
Number of Rows:	1
Outside Diameter:	1.89 in
Series:	41 Series
Thrust Direction:	Single
Width:	0.669 in
