50BTL16 UST

Taper Lock® bushings are similar to QD® style bushings in that they both utilize a split through the taper and flange to provide a true clamp on the shaft that is equivalent to a shrink fit. This type of bushing is retained to the sprocket with a series of set screws on the outside diameter of the bushing running parallel to the shaft or can be welded to the sprocket itself. With Taper Lock® bushings, there is no need for a set screw over the drive shaft key. Taper Lock® bushings offer flexibility in that they allow multiple sized bores for a single bushing size.

Tsubaki® Single Pitch Roller Chain Sprocket, Taper Lock® Type B, 1 in Bore Dia, 3.517 in Outside Dia, #50 Chain, 16 Teeth, 5/8 in Pitch, 3.204 in, 2.781 in Hub Dia, 3/8 in Screw, 3/8 x 3/16 in Keyway, 1 in Length Through Bore, 1610 Taper Lock Bushing, Carbon Steel
