Actual Product May Vary From Image

57120-M3 LEV

Name: 57120-M3 LEV
Brand: Leviton Manufacturing
SKU: 57120-M3 LEV
Availability: OutOfStock

Leviton® 57120-M3 57000 Surge Panel, 30 A, 120/208 VAC, 50/60 Hz, 3 Phase

Manufacturer: Leviton Manufacturing

Manufacturer part number: 57120-M3

Availability: Ships in 5-7 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

Leviton®

Type

Type 2 5-Wire

Description

Leviton® 57000 series SPDs are well suited for electrical service entrance and branch panel environments. Its parallel operated design ensures continuous power even if surge protection is disabled. The 57000 series features indicator lights, a status relay and an audible alarm for monitoring power and surge suppression and replaceable modules that deliver redundant protection.

Leviton® Surge Panel, Series: 57000, 30 A, 120/208 VAC, 50/60 Hz, 3, 100 kA Short Circuit, 150 kA Peak Surge, Modes of Protection: L-N/L-G/N-G/L-L, LED/Noise Filtering/Audible Alarm Indicator, Environmental Conditions: -20 to 40 deg C Operating Temperature, -20 to 85 deg C Storage Temperature, 5 to 95% Non-Condensing Humidity, UL 94 V-2 Flammability, NEMA 12, Panel Mount, 14.19 in H x 10.31 in W x 5 in D, Steel

Application

Commercial

Standards

Features

Protection for up to 150000 A of surge current per mode
Easily replaceable surge modules
AC sine wave tracking provides enhanced EMI/RFI filtering
Real time diagnostics monitor power and surge protection status
Redundant surge modules for mission critical applications
Parallel hardwired, feed through dual wire terminal block, accepts up to 3 AWG wire connection
Surge panel with replaceable surge modules

Specifications

Country of Origin:	MX
Dimensions:	14.19 in H x 10.31 in W x 5 in D
Electrical Ratings:	30 A, 120/208 VAC
Enclosure Type:	NEMA 12
Environmental Conditions:	-20 to 40 deg C Operating Temperature, -20 to 85 deg C Storage Temperature, 5 to 95% Non-Condensing Humidity
Frequency Rating:	50/60 Hz
Indicator Type:	LED/Noise Filtering/Audible Alarm
Material:	Steel
Modes of Protection:	4
Mounting Type:	Panel
Peak Surge Current:	150 kA
Phase:	3
Series:	57000
Short Circuit Current Rating:	100 kA
Wire Size:	3 AWG
