Picture of 5VX1400 GAT
Actual Product May Vary From Image

5VX1400 GAT

Gates® Super HC® 5VX1400 Heavy Duty Molded Notch V-Belt, 5VX Section, 5/8 in W Top, 140 in L Outside, 35/64 in THK, EPDM
Manufacturer: Gates Rubber
Manufacturer part number: 5VX1400
Availability: Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
21 10 10
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 6
Loading...
$132.85

Product Details

Brand Name

Gates®

Type

Heavy Duty Molded Notch

Alternate Supplier #

Motion Industries - 00676979

Description

Constructed with Gates® proprietary construction, this belt has a superior combination of flex and load carrying capacity, as well as transmitting more horsepower than the classical cross-sections in the same amount of drive space.
Gates® Super HC® V-Belt, Heavy Duty Molded Notch, Series: 9414, 5VX Section, 5/8 in Top Width, 140 in Outside Length, 35/64 in Thickness, 1 Rib, 7.958 in Diameter Minimum Pulley, -70 to 250 deg F, EPDM, Flex-Bonded Polyester Reinforced

Application

For all industrial applications, particularly where space, weight and horsepower capacity are critical

Standards

ARPM/RMA IP-3-2/IP-3-3

Features

  • Flex-bonded cords are strongly bonded to the body of the belt resulting in equal load distribution and the absorption of bending stress without cord deterioration
  • Notches molded into the belt during manufacturing increase flexibility making this belt well suited for drives with smaller diameter sheaves
  • Belt edge is machined for even sheave groove contact resulting in smoother running, less slip and wear
  • Patented ethylene material construction provides -70 to 250 deg F temperature range to resist belt cracking

Specifications

Country of Origin:US
Material:EPDM
Minimum Pulley Diameter:7.958 in
Number of Ribs:1
Outside Length:140 in
Reinforced Material:Flex-Bonded Polyester
Section Size:5VX
Series:9414
Temperature Range:-70 to 250 deg F
Thickness:35/64 in
Top Width:5/8 in
