8760 BLN

Name: 8760 BLN
Brand: Omni Cable
SKU: 8760 BLN
Availability: InStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Omni Cable

Manufacturer part number:

8760

Product Name:

8760 BLN

CBT Inventory

313

Vendor Inventory

Availability:

1-2 weeks.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Belden® by Omni Cable

Type

Multi-Conductor Non-Plenum

Description

Belden® by Omni Cable Cable, Multi-Conductor Non-Plenum, 300 VAC, 7.2 A, 1 Pair Conductors, STP Stranded Tinned Copper Conductor, 18 AWG Conductor, 0.222 in OD, 16/30 Strands, 6.5 Ohm Resistance, Polyethylene Insulation, PVC Jacket, -20 to 60 deg C

Standards

UL Style 2092 | EU Directive 2011/65/EU (ROHS II), 2000/53/EC (ELV), 2002/95/EC (RoHS), 2002/96/EC (WEEE) | EU CE Certified | RoHS Compliant | UL1685 Listed

Features

Aluminum foil polyester tape with shorting fold outer shield material
54 lb maximum recommended pulling tension
2-1/4 in minimum bending radius/minor axis

Specifications

Amperage Rating:	7.2 A
Conductor Size:	18 AWG
Conductor Type:	STP Stranded Tinned Copper
Insulation Material:	Polyethylene
Jacket Material:	PVC
Number of Conductors:	1 Pair
Outside Diameter:	0.222 in
Resistance:	6.5 Ohm
Strands:	16/30
Temperature Rating:	-20 to 60 deg C
Voltage Rating:	300 VAC
