A2D1-1/8R FER

Mersen AMP-TRAP® 2000 SmartSpot® A2D1-1/8R Low Voltage North American Style Time Delay Power Fuse, 1.125 A, 250 VAC, 200 kA Interrupt, RK1 Class, Cylindrical Body
Manufacturer: Mersen
Manufacturer part number: A2D1-1/8R
Availability: Expected Leadtime 30 days
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$15.67

Product Details

Brand Name

Mersen

Type

Low Voltage North American Style Time Delay

Alternate Supplier #

Grainger - 4TAW4

Description

Amp-Trap® 2000 SmartSpot® time delay A2D-R fuses provide IEC type-2 "no damage" protection to existing mains, feeders and branch circuits serving motor and non-motor loads. A2D-R fuses will open fast enough under extreme fault conditions for maximum short circuit protection to prevent damage to motor starters, switches and other circuit components, yet also provide the time delay needed for motor inrush currents. A2D-R fuses can be used to replace obsolete 250 V class H, K or RK5 fuses already installed in the field.
Mersen AMP-TRAP® 2000 SmartSpot® Power Fuse, Low Voltage North American Style Time Delay, Series: A2D-R, Indicating, Rejection, 1.125 A, 250 VAC, 200 kA Interrupt, Class: RK1, Ferrule Terminal, Clip Mounting, Cylindrical Body, Polyester, 9/16 in Dia x 2 in L Body

Application

Motor, Safety Switches, Transformers, Disconnects, Control Panel and All General Purpose Circuits Applications

Standards

Class 1422-02 File No. 012636_0_000 | CSA C22.2 No. 248.12 | RoHS Compliant | UL 248-12 Guide JDDZ File No. E2137

Features

  • Solid state SmartSpot® indicator
  • Time delay for motor starting and transformer inrush currents without nuisance opening
  • 300 kA interrupting rating, self certified (UL witnessed)
  • Extremely current limiting for low peak let-thru current
  • Easy 2-to-1 selectivity for prevention of nuisance shutdowns and "blackouts"
  • Rejection style design prevents replacement errors (when used with recommended fuse blocks)
  • High visibility orange label gives instant recognition
  • Reduced inventory by taking the place of class RK5, K and H fuses
  • Metal embossed date and catalog number for easier traceability and lasting identification
  • Fiberglass body provides dimensional stability in harsh industrial settings
  • High grade silica filler ensures fast arc quenching
  • 200 kA at 250 VAC, 100 kA at 250 VDC interrupt rating

Specifications

Amperage Rating:1.125 A
Body Size:9/16 in Dia x 2 in L
Body Type:Cylindrical
Class:RK1
Country of Origin:MX
Indicating/Non-Indicating:Indicating
Interrupt Rating:200 kA
Material:Polyester
Mounting Type:Clip
Rejection/Non-Rejection:Rejection
Series:A2D-R
Terminal Type:Ferrule
Voltage Rating:250 VAC
