Actual Product May Vary From Image

A6D80R FER

Name: A6D80R FER
Brand: Mersen
SKU: A6D80R FER
Price: 93.84 USD
Availability: OutOfStock

Mersen AMP-TRAP® 2000 SmartSpot® A6D80R Current Limiting Low Voltage North American Time Delay Power Fuse, 80 A, 600 VAC, 200 kA Interrupt, RK1 Class, Cylindrical Body

Manufacturer: Mersen

Manufacturer part number: A6D80R

Availability: Expected Leadtime 15 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$93.84

Qty:

Product Details

Brand Name

Mersen

Type

Current Limiting Low Voltage North American Time Delay

Alternate Supplier #

Grainger - 4TCH8

Description

Amp-Trap® 2000 SmartSpot® time delay A6D-R fuses provide IEC type-2 "no damage" protection to existing mains, feeders and branch circuits serving motor and non-motor loads. A6D-R fuses will open fast enough under extreme fault conditions for maximum short circuit protection to prevent damage to motor starters, switches and other circuit components, yet also provide the time delay needed for motor inrush currents. A6D-R fuses can be used to replace obsolete 600 VAC class H, K or RK5 fuses already installed in the field.

Mersen AMP-TRAP® 2000 SmartSpot® Power Fuse, Current Limiting Low Voltage North American Time Delay, Series: A6D-R, Indicating, Rejection, 80 A, 600 VAC, 200 kA Interrupt, Class: RK1, Blade Terminal, Clip Mounting, Cylindrical Body, Dual Element, Fiberglass, 1-5/16 in Dia x 7-7/8 in L Body

Application

Motor, Safety Switches, Transformers, Disconnects, Control Panel and All General Purpose Circuits Applications

Standards

CSA C22.2 No. 248.12 | DC Listed | UL 248 | UL 248-12 File No. E2137

Features

Solid state SmartSpot® indicator
Time delay for motor starting and transformer inrush currents without nuisance opening
300 kA interrupting rating, self certified (UL witnessed)
Extremely current limiting for low peak let-thru current
Easy 2-to-1 selectivity for prevention of nuisance shutdowns and "blackouts"
Rejection style design prevents replacement errors (when used with recommended fuse blocks)
High visibility orange label gives instant recognition
Reduced inventory by taking the place of class RK5, K and H fuses
Metal embossed date and catalog number for easier traceability and lasting identification
Fiberglass body provides dimensional stability in harsh industrial settings
High grade silica filler ensures fast arc quenching
Recommended for arc flash energy reduction
A6D-R fuses will open fast enough under extreme fault conditions for maximum short
Plated terminals
Arc flash mitigating
Tin-plated copper contact

Specifications

Amperage Rating:	80 A
Body Size:	1-5/16 in Dia x 7-7/8 in L
Body Type:	Cylindrical
Class:	RK1
Country of Origin:	MX
Element:	Dual
Indicating/Non-Indicating:	Indicating
Interrupt Rating:	200 kA
Material:	Fiberglass
Mounting Type:	Clip
Rejection/Non-Rejection:	Rejection
Series:	A6D-R
Terminal Type:	Blade
Voltage Rating:	600 VAC
