ABC-1-R BSF

Name: ABC-1-R BSF
Brand: Bussmann
SKU: ABC-1-R BSF
Price: 4.14 USD
Availability: InStock

Bussmann ABC-1-R Small Dimension Fast Acting Fuse With Nickel Plated Brass End Cap, 1 A, 250 VAC, 125 VDC, 35 A, 10 kA Interrupt, Cylindrical Body

Manufacturer: Bussmann

Manufacturer part number: ABC-1-R

Availability: Expected Leadtime 14 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	10
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...

$4.14

Qty:

Product Details

Brand Name

Bussmann

Type

Small Dimension

Alternate Supplier #

Grainger - 6F038

Description

Fast-acting, ceramic tube 1/4" x 1-1/4" ferrule fuse designed to UL 248-14 for overcurrent protection of electronic circuits. Install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available axial leads for thru-hole installation. Eaton's ABC fast-acting, ceramic body tube 1/4" x 1-1/4" fuses are designed with higher interrupting ratings and voltage ratings to UL 248-14 for overcurrent protection of electronic circuits. This is a RoHS compliant fuse. Order in cartridge fuse format and install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available axial leads for thru-hole installation.

Bussmann Fast Acting Fuse, Small Dimension, Series: ABC, Non-Indicating, Non-Rejection, 1 A, 250 VAC, 125 VDC, 35 A, 10 kA Interrupt, 4 hr, 60 min, 120 s Response, Ferrule Terminal, Holder Mounting, Cylindrical Body, Single Element, Ceramic, 1/4 in Dia x 1-1/4 in L Body

Application

Electronic Circuit Applications

Standards

RoHS 2002/95/EC | UL 248-14 | Guide JDYX/File No. E19180 | CSA Class 1422-01/1422-30/File No. 53787 | CE Certified

Features

Ceramic body allows for higher amp/volt rating combinations
35 A at 250 VAC, 10 kA at 125 VAC/VDC interrupt rating
4 hr minimum at 100%, 60 min maximum at 135%, 120 sec maximum at 200% response time

Specifications

Amperage Rating:	1 A
Body Size:	1/4 in Dia x 1-1/4 in L
Body Type:	Cylindrical
Country of Origin:	CN
Element:	Single
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	35 A, 10 kA
Material:	Ceramic
Mounting Type:	Clip/Holder
Rejection/Non-Rejection:	Non-Rejection
Response Time:	4 hr, 60 min, 120 s
Series:	ABC
Terminal Type:	Ferrule
Voltage Rating:	250 VAC, 125 VDC
