ATMR10 FER

Product Details

Manufacturer:
Manufacturer part number:
ATMR10
product.name:
ATMR10 FER
CBT Inventory
60
Vendor Inventory
Loading...
CBT - Cincinnati
24
CBT - Springboro
36
CBT - Sidney
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Expected Leadtime 15 days
Estimated dates are contingent upon manufacturer stock.
$20.64 / EA

Description

Brand Name

Mersen

Alternate Supplier #

Grainger - 4ZCA2

Description

Amp-Trap® ATMR fuses, in the Class CC family, are the smallest dimension 600V fuses suitable for branch circuit protection. The ATMR is a popular choice for economical protection of control circuits and control circuit transformers where available short circuit currents exceed 10,000 amperes. ATMR's rejection dimensions prevent substitution by lesser rated fuses. These fast acting fuses give current limiting protection to general circuits.
Mersen Amp-Trap® Fast Acting Fuse, Series: ATMR, Non-Indicating, Rejection, 10 A, 600 VAC/VDC, 200/100 kA Interrupt, Class: CC, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Single Element, GMG, 13/32 in Dia x 1-1/2 in L Body Size

Application

Control Circuits, Lighting, General Loads and Branch Circuit Protection Applications

Standards

UL 248-4 | CSA C22.2 No. 248.4 | RoHS Compliant

Features

  • Rejection style design prevents replacement errors when used with recommended fuse blocks
  • Fiberglass body provides dimensional stability in harsh industrial environments
  • Versatile design for individual component and branch circuit protection
  • Tin-plated copper contact material
  • North American power fuses

Specifications

Amperage Rating:10 A
Body Size:13/32 in Dia x 1-1/2 in L
Body Type:Cylindrical
Class:CC
Country of Origin:MX
Element:Single
Indicating/Non-Indicating:Non-Indicating
Interrupt Rating:200/100 kA
Material:GMG
Mounting Type:Holder
Rejection/Non-Rejection:Rejection
Series:ATMR
Terminal Type:Ferrule
Voltage Rating:600 VAC/VDC
