Actual Product May Vary From Image

BX86 GAT

Name: BX86 GAT
Brand: Gates Rubber
SKU: BX86 GAT
Price: 39.24 USD
Availability: InStock

Gates® Tri-Power® BX86 Heavy Duty Molded Notch V-Belt, BX Section, 21/32 in W Top, 89 in L Outside, 13/32 in THK, EPDM

Manufacturer: Gates Rubber

Manufacturer part number: BX86

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
4	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$39.24

Qty:

Product Details

Brand Name

Gates®

Type

Heavy Duty Molded Notch

Description

Constructed with Gates® proprietary construction, this belt has a superior combination of flex and load carrying capacity, as well as less stretch resulting in less maintenance.

Gates® Tri-Power® V-Belt, Heavy Duty Molded Notch, Series: 9013, BX Section, 21/32 in Top Width, 89 in Outside Length, 13/32 in Thickness, 1 Rib, 4.775 in Diameter Minimum Pulley, -70 to 250 deg F, EPDM, Flex-Bonded Polyester Reinforced

Application

For all industrial applications, particularly where small or sub-minimal sheave diameters are required

Standards

ARPM/RMA IP-3-2/IP-3-3

Features

Flex-bonded cords are strongly bonded to the body of the belt resulting in equal load distribution and the absorption of bending stress without cord deterioration
Notches molded into the belt during manufacturing increase flexibility making this belt well suited for drives with smaller diameter sheaves
Belt edge is machined for even sheave groove contact resulting in smoother running, less slip and wear
Patented ethylene material construction provides -70 to 250 deg F temperature range to resist belt cracking

Specifications

Country of Origin:	US
Material:	EPDM
Minimum Pulley Diameter:	4.775 in
Number of Ribs:	1
Outside Length:	89 in
Reinforced Material:	Flex-Bonded Polyester
Section Size:	BX
Series:	9013
Temperature Range:	-70 to 250 deg F
Thickness:	13/32 in
Top Width:	21/32 in
