Actual Product May Vary From Image

CR20I HWD

Name: CR20I HWD
Brand: Hubbell Wiring Device-Kellems
SKU: CR20I HWD
Price: 1.87 USD
Availability: InStock

Wiring Device-Kellems CR20I 1-Phase Duplex Self-Grounding Standard Traditional Screw Mount Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Ivory

Manufacturer: Hubbell Wiring Device-Kellems

Manufacturer part number: CR20I

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
12	6	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$1.87

Qty:

Product Details

Brand Name

Wiring Device-Kellems

Type

1-Phase Duplex Self-Grounding Standard Traditional Screw Mount

Alternate Supplier #

Grainger - 6A671

Description

Wiring Device-Kellems Straight Blade Receptacle, 1-Phase Duplex Self-Grounding Standard Traditional Screw Mount, 125 VAC, 20 A, 1 hp, 2 Pole, 3 Wires, 5-20R NEMA Rating, Commercial/Specification Grade, -40 to 75 deg C, Side Wired Terminal, Nylon, Ivory, 1.32 x 0.83 x 3.28 in

Application

Commercial and Specification Grade Applications

Standards

Features

Easy access split circuit tab
Fork terminal capable
Smooth face, traditional face, triple wipe contacts
#8 to 32 brass, multiple drive terminal screw material, #8 to 32 brass, multiple drive (green) ground screw material
Nylon top and base material, 0.031 in (0.8) phosphor bronze power contacts material, 0.04 in (1) steel (galvanized) mounting strap material, 0.032 in (0.8) steel wire auto ground clip material
Steel-zinc plated mounting screw material
Withstands 2000 V minimum dielectric voltage
Certified for current interrupting at full rated current
Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75% temperature rise
Terminals identified in accordance with UL 498 (brass, white, green)
NO 14 to 10 AWG copper stranded or solid conductor only terminal accommodation
UL 94V-2 flammability

Specifications

Amperage Rating:	20 A
Color:	Ivory
Country of Origin:	CN
Dimensions:	1.32 x 0.83 x 3.28 in
Grade:	Commercial/Specification
Horsepower:	1 hp
Material:	Nylon
NEMA Rating:	5-20R
Number of Poles:	2
Number of Wires:	3
Series:	Commercial
Temperature Rating:	-40 to 75 deg C
Terminal Type:	Side Wire
Voltage Rating:	125 VAC
