Actual Product May Vary From Image

CYR 1 3/4 S MCG

Name: CYR 1 3/4 S MCG
Brand: Regal Rexnord
SKU: CYR 1 3/4 S MCG
Price: 41.39 USD
Availability: OutOfStock

McGill® CAMROL® 4160110000 CYR Cylindrical OD Unmounted Cam Yoke Roller Bearing With LUBRI-DISC® Seal, 1/2 in Dia Bore, 1-3/4 in Dia x 1 in W Roller, 6385 lb Dynamic/14800 lb Static Load, Chrome Steel Roller

Manufacturer: Regal Rexnord

Manufacturer part number: 4160110000

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$41.39

Qty:

Product Details

Brand Name

McGill®

Type

Cylindrical OD

Description

The McGill® CAMROL® full complement needle bearings feature black oxide treated bearing steel. They are available in two basic mounting styles for use in mechanical automation or linear motion applications. Our basic features each contribute to superior performance. The LUBRIDISC® seal option helps prevent metal to metal contact within the bearing. It also provides a barrier for containment entry and blowout protection when relubricating. These bearings are available with several dimensional choices. The seal options and combinations provide a specific solution for each application. Within the following section you can learn more about these features and how they can be applied to your application.

McGill® CAMROL® Unmounted Cam Yoke Roller Bearing, Cylindrical OD, Series: CYR, 1/2 in Bore Dia, 1-3/4 in Roller Dia, 1 in Roller Width, 1-1/16 in Overall Width, 6385 lb Dynamic/14800 lb Static, Sealed Closure, 2200 rpm Maximum, -20 to 250 deg F, Chrome Steel Roller, Black Oxide

Application

Unit Handling, Minerals and Mining Industries

Features

Full complement needle roller construction provides high radial load capacity, it also provides improved resistance to shock loading versus caged needle bearing
A heavy sectioned outer race design to help withstand shock loading of cam follower operation
Inner studs are induction heat treated in the roller path and flange surfaces
Black oxide finish on all external surfaces helps inhibit corrosion
The annular groove in the outer raceway provides a lubrication reservoir which helps prolong lubrication intervals
Needle roller bearing element

Specifications

Bore Diameter:	1/2 in
Closure Type:	Sealed
Country of Origin:	MX
Finish:	Black Oxide
Load Capacity:	6385 lb Dynamic/14800 lb Static
Maximum Speed:	2200 rpm
Overall Width:	1-1/16 in
Roller Diameter:	1-3/4 in
Roller Material:	Chrome Steel
Roller Width:	1 in
Series:	CYR
Temperature Rating:	-20 to 250 deg F
