FLSR200ID LIT

Name: FLSR200ID LIT
Brand: Littelfuse
SKU: FLSR200ID LIT
Price: 178.20 USD
Availability: OutOfStock

Littelfuse® POWR-GARD® FLSR200ID Current Limiting Time Delay Fuse, 200 A, 600 VAC/300 VDC, 200/20 kA Interrupt, RK5 Class, Cylindrical Body

Manufacturer: Littelfuse

Manufacturer part number: FLSR200ID

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$178.20

Qty:

Product Details

Brand Name

Littelfuse®

Type

Current Limiting

Description

Littelfuse® FLSR series fuses have been the superior UL Class RK5 dual element time delay fuses and are the most widely used Class of fuses. FLSR series fuses provide excellent protection for all types of circuits especially those containing motors. However, users and specifiers should consider the significant benefits offered by indicator fuses.

Littelfuse® POWR-GARD® Time Delay Fuse, Current Limiting, Series: FLSR, Indicating, Rejection, 200 A, 600 VAC/300 VDC, 200/20 kA Interrupt, Class: RK5, 50/60 Hz Frequency, 10 s Response, Knife Blade Terminal, Holder Mounting, Cylindrical Body, Dual Element, Composite, 1-27/32 in Dia x 9-5/8 in L Body

Application

Service Entrance Switches, Transformers, Switchboard Mains and Feeders, Motor Control Central Mains, Motor Branch Circuits and All General Purpose Circuits Applications

Standards

UL 248-12 | E81895 | CSA LR29862 | Federal Specification WF-1814 | PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer

Features

Reliable interruption of all over currents upto 200 kA
Faster acting short circuit protection than any non-current limiting mechanical protective device
Accurate and reliable - automated, precision manufactured and assembled parts ensure accurate, consistent response to overloads and short circuits
300 kA rms symmetrical self certified
Copper caps

Specifications

Amperage Rating:	200 A
Body Size:	1-27/32 in Dia x 9-5/8 in L
Body Type:	Cylindrical
Class:	RK5
Country of Origin:	MX
Element:	Dual
Frequency Rating:	50/60 Hz
Indicating/Non-Indicating:	Indicating
Interrupt Rating:	200/20 kA
Material:	Composite
Mounting Type:	Holder
Rejection/Non-Rejection:	Rejection
Response Time:	10 s
Series:	FLSR
Terminal Type:	Knife Blade
Voltage Rating:	600 VAC/300 VDC
