FWP-175A BSF

High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.

Bussmann High Speed Fuse, Fast Acting, Series: FWP, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 175 A, 700 VAC/VDC, 50/200 kA Interrupt, 45 to 1000 Hz, Blade Terminal, Stud Mount, Cylindrical Body Type, Single Element, Ceramic, 1.5 in Dia x 5.09 in L Body Size
