G229 BOS

Boston Gear® G229 Plain Spur Gear Without Keyway or Setscrews, 16 Diametral Pitch, 14.5 deg, 0.313 in Face W, 12 Teeth, 3/4 in Pitch Dia, 1/4 in Bore Dia, Brass
Manufacturer: Boston Gear
Manufacturer part number: G229
Availability: Ships in 3-5 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
50 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$24.23

Product Details

Brand Name

Boston Gear®

Type

Plain

Description

Boston Gear® spur gears are designed to transmit motion and power between parallel shafts. The different styles offered include spur, gear rack, pinion wire, stem pinions and internal gears and most come with a selection of bore diameters, keyways and setscrews to accommodate a wide variety of application requirements. They are available in plastic, non-metallic, brass, steel and cast iron and are manufactured in a variety of styles, including plain, web, web with lightening holes and web with spokes. Many are available with or without hubs. Boston Gear® manufactures both 14-1/2 deg and 20 deg PA, involute, full-depth system gears. While 20 deg PA is generally recognized as having a higher load-carrying capacity, 14-1/2 deg PA gears are used extensively because of lower backlash and smoother, quieter operation.
Boston Gear® Spur Gear Without Keyway or Setscrews, Plain, 1/4 in Bore Dia, 0.88 in Outside Dia, 12 Teeth, 16 Diametral Pitch, 3/4 in, 0.313 in Face Width, 0.313 in Overall Length, 14.5 deg Pressure Angle, Brass

Application

For parallel shaft applications

Standards

PROP65: This product contains lead, known to the State of California to cause cancer and birth defects or other reproductive harm.

Features

  • More cost effective, quieter running and corrosion resistant operation
  • Will not operate with 20 deg spurs

Specifications

Bore Diameter:1/4 in
Country of Origin:US
Diametral Pitch:16
Face Width:0.313 in
Material:Brass
Number of Teeth:12
Outside Diameter:0.88 in
Overall Length:0.313 in
Pitch Diameter:3/4 in
Pressure Angle:14.5 deg
