GDA-2.5A BSF

Name: GDA-2.5A BSF
Brand: Bussmann
SKU: GDA-2.5A BSF
Price: 12.64 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Bussmann

Manufacturer part number:

GDA-2.5A

CBT Inventory

Vendor Inventory

Availability:

Expected Leadtime 21 days

Estimated dates are contingent upon manufacturer stock.

$12.64 / EA

Description

Brand Name

Bussmann

Type

High Breaking Small Dimension

Description

Fast-acting, high breaking capacity 5 mm x 20 mm ferrule fuse designed to IEC 60127-2 for overcurrent protection of electronic circuits. Install into a Bussmann Series fuse holder, block or fuse clip. Also available axial leads for thru-hole installation. Eaton's GSA fast-acting, high breaking capacity 5mm x 20mm ferrule fuses are designed to IEC 60127-2 for overcurrent protection of electronic circuits. Order in cartridge fuse format and install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available axial leads for thru-hole installation.

Bussmann Fast Acting Fuse, High Breaking Small Dimension, Series: GDA, Non-Indicating, Non-Rejection, 2.5 A, 250 VAC, 1.5 kA Interrupt, 50 Hz Frequency, 60 min Response, Ferrule Terminal, Holder Mounting, Cylindrical Body, Single Element, Ceramic, 5.2 mm Dia x 20 mm L Body

Application

Electronic Circuits

Standards

Features

Fast acting for maximum component protection
High break capacity for use in higher fault energy electronic circuitry
1.5 kA at 250 VAC interrupt rating

Specifications

Amperage Rating:	2.5 A
Body Size:	5.2 mm Dia x 20 mm H
Body Type:	Cylindrical
Country of Origin:	CN
Element:	Single
Frequency Rating:	50 Hz
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	1.5 kA
Material:	Ceramic
Mounting Type:	Clip/Holder
Rejection/Non-Rejection:	Non-Rejection
Response Time:	60 min
Series:	GDA
Terminal Type:	Ferrule
Voltage Rating:	250 VAC
