Actual Product May Vary From Image

H50B22 UST

Name: H50B22 UST
Brand: US Tsubaki
SKU: H50B22 UST
Price: 48.83 USD
Availability: OutOfStock

Tsubaki® H50B22 Stock Bore Roller Chain Sprocket, 3/4 in Dia Bore, 4.722 in OD, #50 Chain, 22 Teeth, 4.392 in Dia Pitch, 1045 Cold Rolled Carbon Steel

Manufacturer: US Tsubaki

Manufacturer part number: H50B22

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$48.83

Qty:

Product Details

Brand Name

Tsubaki®

Type

Stock Bore

Description

Associated with A, B and C style sprockets where there is no special machining performed to accommodate keyways or set screws, only a hole to accommodate shaft diameter.

Tsubaki® Roller Chain Sprocket, Stock Bore, 3/4 in Bore Dia, 4.722 in Outside Dia, #50 Chain, 22 Teeth, 5/8 in Pitch, 4.392 in, 3 in Hub Dia, 1-1/4 in Length Through Bore, 1045 Cold Rolled Carbon Steel, Black Oxide

Application

Oil and Gas, Lumber, Mining, Primary Metals, Material Handling, Conveyor, Civil Engineering Projects, Machine Tool, Marine, Packaging Machinery, Pulp and Paper, Food Processing and Forestry Applications

Standards

ANSI Specified

Features

Extends chain life up to 50%
Offers up to twice the wear life
Can be used in abrasive conditions
Absorbs high shock loads
Saves downtime and replacement costs
Can be used in heavy loaded applications
Ideal for high speeds
H - Hardened teeth
Type B - Hub extension on one-side

Specifications

Bore Diameter:	3/4 in
Chain Size:	#50
Country of Origin:	CN
Finish:	Black Oxide
Hub Diameter:	3 in
Length Through Bore:	1-1/4 in
Material:	1045 Cold Rolled Carbon Steel
Number of Teeth:	22
Outside Diameter:	4.722 in
Pitch:	5/8 in
Pitch Diameter:	4.392 in
