HBL4720C HWD

Picture of HBL4720C HWD
Actual Product May Vary From Image

Product Details

Manufacturer:
Hubbell Wiring Device-Kellems
Manufacturer part number:
HBL4720C
product.name:
HBL4720C HWD
CBT Inventory
18
Vendor Inventory
Loading...
Availability:
Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
$23.51 / EA

Description

Brand Name

Wiring Device-Kellems

Type

1-Phase Extra Heavy Duty Grounding Standard Sized Male

Alternate Supplier #

Grainger - 5A073

Description

Hubbell® Insulgrip® plugs and connectors continue our long standing tradition of leadership as well as innovative design. The tough nylon body provides impact and chemical resistance commonly needed in the entertainment industry. The durable and powerful offsetting cord grip clamps on individual conductors and outer cord jackets prevent strain on the terminals. Its these and many other features that set Hubbell® performance above all others.
Wiring Device-Kellems Twist-Lock® Insulgrip® Locking Plug, 1-Phase Extra Heavy Duty Grounding Standard Sized Male, Series: HBL®, 125 VAC, 15 A, 1/2 hp, 2 Poles, 3 Wires, NEMA L5-15P, Industrial Grade, IP20 Enclosure, 0.23 to 0.72 in Cord Dia, -40 to 75 deg C, Pressure Screw Terminal, Composite, Black/White, 1.53 in L x 1.53 in W x 1.97 in H

Application

Power Connection Applications

Standards

UL 498 | CSA C22.2 No. 42 | Federal Specification WC596 | NEMA WD1/WD5

Features

  • Individually molded face for each blade configuration keeps debris out of plug interior
  • Roomy wiring chamber provides ample space for wiring
  • Ribbed nylon housing provides a secure grip that impact and chemical resistant
  • Natural white nylon blade holder, cord clamp
  • Clear polycarbonate terminal retainer
  • Brass blade, terminal screw and ground screw
  • Steel nickel plated terminal clamp
  • Steel, zinc plated cord clamp screw, body holding screw
  • Withstands 2000 VAC minimum dielectric voltage

Specifications

Amperage Rating:15 A
Color:Black/White
Cord Diameter:0.23 to 0.72 in
Country of Origin:US
Dimensions:1.53 in L x 1.53 in W x 1.97 in H
Enclosure:IP20
Grade:Industrial
Horsepower:1/2 hp
Material:Composite
NEMA Rating:L5-15P
Number of Poles:2
Number of Wires:3
Series:HBL®
Temperature Rating:-40 to 75 deg C
Terminal Type:Pressure Screw
Voltage Rating:125 VAC
