Actual Product May Vary From Image

HBL7485 HWD

Name: HBL7485 HWD
Brand: Hubbell Wiring Device-Kellems
SKU: HBL7485 HWD
Price: 23.67 USD
Availability: OutOfStock

Wiring Device-Kellems Twist-Lock® HBL7485 1-Phase Male Midget Non-Grounding Straight Cord Mount Locking Plug, 125/250 VAC, 15 A, 3 Poles, 3 Wires, Black

Manufacturer: Hubbell Wiring Device-Kellems

Manufacturer part number: HBL7485

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$23.67

Qty:

Product Details

Brand Name

Wiring Device-Kellems

Type

1-Phase Male Midget Non-Grounding Straight Cord Mount

Alternate Supplier #

Grainger - 5Z909

Description

Wiring Device-Kellems Twist-Lock® Locking Plug, 1-Phase Male Midget Non-Grounding Straight Cord Mount, 125/250 VAC, 15 A, 3 Pole, 3 Wires, ML-3P NEMA Rating, Industrial Grade, IP20 Enclosure, 0.281 to 0.421 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Nylon, Black, 1.17 x 1.17 x 2.45 in

Application

Commercial and Industrial Applications

Standards

RoHS Compliant | UL 498 | CSA C22.2 No. 42

Features

Abuse resistant nylon housing
Phenolic body for high heat resistance
Angled body design for low profile in tight spaces
Totally insulated body adds extra measure of safety
Midget locking display
Withstands 2000 VAC minimum dielectric voltage
Brass blade, phenolic blade holder
#5-40 brass terminal screw
Zinc plated steel with black lacquer finish terminal clamp

Specifications

Amperage Rating:	15 A
Color:	Black
Cord Diameter:	0.281 to 0.421 in
Country of Origin:	US
Dimensions:	1.17 in L x 1.17 in W x 2.45 in H
Enclosure:	IP20
Grade:	Commercial/Industrial
Material:	Composite
NEMA Rating:	ML-3P
Number of Poles:	3
Number of Wires:	3
Series:	HBL®
Temperature Rating:	-40 to 75 deg C
Terminal Type:	Pressure Screw
Voltage Rating:	125/250 VAC
