HOW TO: Measure Multi-Point Belt Drives

Measuring multi-point belt drives can be tricky. When you have a drive with more than one sprocket, the standard two-point equation will not provide accurate results. CBT partner Gates Corporation demonstrates how to accurately measure your multi-point belt drive with a simple x-y chart. https://www.youtube.com/watch?v=Y_lcYIUBDAc&list=PL0326F7D53BD018D1&index=1 For more guidance measuring your multi-point belt drive, contact your CBT mechanical specialist today.
