Actual Product May Vary From Image

KLKR010 LIT

Name: KLKR010 LIT
Brand: Littelfuse
SKU: KLKR010 LIT
Price: 37.48 USD
Availability: OutOfStock

Littelfuse® POWR-GARD® KLKR010 High Speed North American Style Fast Acting Fuse, 10 A, 600 VAC/300 VDC, 20/200 kA Interrupt, CC Class, Cartridge Body

Manufacturer: Littelfuse

Manufacturer part number: KLKR010

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$37.48

Qty:

Product Details

Brand Name

Littelfuse®

Type

High Speed North American Style

Alternate Supplier #

Grainger - 486M75

Description

KLKR series Class CC fuses are fast acting fuses intended for general purpose branch circuit protection. Their compact size, fast acting overload response and their highly current limiting design make them ideal for use in OEM equipment and control panels because solid state devices such as SCRs and other electronic equipment generally require fast acting protection.

Littelfuse® POWR-GARD® Fast Acting Fuse, High Speed North American Style, Series: KLKR, Non-Indicating, Rejection, 10 A, 600 VAC/300 VDC, 20/200 kA Interrupt, Class: CC, 12 s Response, Ferrule Terminal, Holder Mounting, Cartridge Body, Melamine, 13/32 in Dia x 1-1/2 in L Body

Application

General Purpose Protections Equipment Requiring Fast Overload Protection Applications

Standards

UL 248-8 | CSA Certified | PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer

Features

Rejection feature prevents use of fuses with lower interrupting ratings or voltage ratings when used with corresponding fuse holders
Extremely current limiting reduces damage caused by heating and magnetic effects of short circuit currents
Provide superior protection in a fraction of the space required by other fuse classes
200 kA at 600 VAC, 20 kA at 300 VDC interrupting rating
Nickel plated bronze cap
12 s minimum and 4 min maximum at 200%, 1 hr maximum at 135%, 15 min minimum at 110%

Specifications

Amperage Rating:	10 A
Body Size:	13/32 in Dia x 1-1/2 in L
Body Type:	Cartridge
Class:	CC
Country of Origin:	MX
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	20/200 kA
Material:	Melamine
Mounting Type:	Holder
Rejection/Non-Rejection:	Rejection
Response Time:	12 s
Series:	KLKR
Terminal Type:	Ferrule
Voltage Rating:	600 VAC/300 VDC
