KQ2H11-36AS SMC

Name: KQ2H11-36AS SMC
Brand: SMC
SKU: KQ2H11-36AS SMC
Price: 3.67 USD
Availability: InStock

SMC® KQ2H11-36AS KQ2 Inch Size with Sealant One Touch Fitting, 3/8 x 3/8 in Nominal, Push-In x Male NPT End Style, Brass

Manufacturer: SMC

Manufacturer part number: KQ2H11-36AS

Availability: Ships in 2-4 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
22	10	8
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$3.67

Qty:

Product Details

Brand Name

SMC®

Type

Inch Size with Sealant

Description

SMC®, KQ2H11-36AS, One Touch Fitting, Inch Size with Sealant, Series: KQ2, Fitting/Connector: Connector, 3/8 x 3/8 in Nominal, Push-In x Male NPT End Style, 17.46 mm Hex, 22.7 mm Length, -100 kPa to 1 MPa Pressure, -5 to 60 deg C Air, 0 to 40 deg C Water Operating, Brass, Gray/White

Application

Used for a wide range of pressures from a low vacuum up to a pressure

Standards

RoHS Compliant

Features

Accepts nylon and polyurethane tubes
Stud allows rotation of the body for ease of installation in confined spaces
Release collar allows easy removal of tubing without damaging the tube
Can be used for a wide range of pressures from a low vacuum up to a pressure of 1.0MPa
This product is not intended for use in potable water systems

Specifications

Color:	Gray/White
Country of Origin:	JP
End Style:	Push-In x Male NPT
Fitting/Connector Type:	Connector
Hex Size:	17.46 mm
Length:	22.7 mm
Material:	Brass
Nominal Size:	3/8 x 3/8 in
Pressure Rating:	-100 kPa to 1 MPa
Series:	KQ2
Temperature Rating:	-5 to 60 deg C Air, 0 to 40 deg C Water Operating
