Actual Product May Vary From Image

KTK-R-2 BSF

Name: KTK-R-2 BSF
Brand: Bussmann
SKU: KTK-R-2 BSF
Price: 58.72 USD
Availability: OutOfStock

Bussmann Limitron™ KTK-R-2 Fast Acting Fuse, 2 A, 600 VAC, 200 kA, Class CC, Cylindrical Body

Manufacturer: Bussmann

Manufacturer part number: KTK-R-2

Availability: Expected Leadtime 7 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...

$58.72

Qty:

Product Details

Brand Name

Bussmann

Alternate Supplier #

Grainger - 4XC21

Description

Bussmann's Class CC fuses set the standard in Class CC fuse performance in the industry. Recognized for their superior performance, Bussmann has the right product for your circuit and equipment protection needs. These branch circuit rated, 600v, 200,000a IR fuses offer exceptional protection in the smallest package of any UL class of fuses. Choose from the ultimate protection provided by our Low Peak LP-CC fuses, the time delay of our FNQ-R's for your control transformer and similar control applications or the fast acting protection of our KTK-R Limitron fuses for specialized circuits such as lighting protection

Bussmann Limitron™ Fast Acting Fuse, Series: KTK-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 2 A, 600 VAC, 200 kA Interrupt, Class: CC, Ferrule Terminal, Holder Mount, Cylindrical Body, Single Element, Melamine, 13/32 in Dia x 1-1/2 in L Body Size

Application

Branch Circuits, Specialized Circuits, Industrial Control and Street Lighting Applications

Standards

UL 248-4 | CSA C22.2, CE Certified

Features

Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
200 kA VAC (RMS symmetrical) interrupt rating complies with NEC section 110.9 for today's large capacity systems
Fast acting fuse helps prevent equipment damage caused by short circuit events
Rejection type fuse fits both standard and rejection style holders
Ideal for critical industrial or commercial applications that have specific current limitation requirements
Nickel plated bronze endcaps
Class CC rejection feature, with appropriate fuse block, prevents inserting lesser rated supplementary fuses

Specifications

Amperage Rating:	2 A
Body Size:	13/32 in Dia x 1-1/2 in L
Body Type:	Cylindrical
Class:	CC
Country of Origin:	MX
Element:	Single
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	200 kA
Material:	Melamine
Mounting Type:	Holder
Rejection/Non-Rejection:	Rejection
Series:	KTK-R
Terminal Type:	Ferrule
Voltage Rating:	600 VAC

Resources
