Actual Product May Vary From Image

LP-CC-15 BSF

Name: LP-CC-15 BSF
Brand: Bussmann
SKU: LP-CC-15 BSF
Price: 73.37 USD
Availability: InStock

Bussmann Low-Peak™ LP-CC-15 Current Limiting Time Delay Fuse, 15 A, 600 VAC/150 VDC, 20/200 kA Interrupt, CC Class, Cylindrical Body

Manufacturer: Bussmann

Manufacturer part number: LP-CC-15

Availability: Expected Leadtime 7 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	83
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...

$73.37

Qty:

Product Details

Brand Name

Bussmann

Type

Current Limiting

Alternate Supplier #

Grainger - 1CX48
Fastenal - 0761229

Description

EATON Bussmann series Low-Peak™ ultimate protection fuses are the industry's only UL listed and CSA Certified fuses with a 300 kA interrupting rating, providing 50% more protection than any other listed fuse. The high interrupting rating allows for simple, worry-free installation in virtually any application. Low peak fuses are available in class CC, CF, J, L and RK1, so there is a fuse to meet the vast majority of 600 VAC over current protection needs. Plus, when upgrading to Low-Peak™ fuses, existing fuse inventory can be reduced by up to 33%.

Bussmann Low-Peak™ Time Delay Fuse, Current Limiting, Series: LP-CC, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 15 A, 600 VAC/150 VDC, 20/200 kA Interrupt, Class: CC, 12 s at 200% Response, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Dual Element, Melamine, Yellow, 13/32 in Dia x 1-1/2 in L Body Size

Application

Branch Circuits, Specialized Circuits, Industrial Control and Street Lighting Applications, Safety and Security Systems

Standards

CE Certified | CSA 53787 | NEC 110.9 | RoHS Compliant | UL 198L File No.E4273/248-4 Guide JDDZ

Features

Time delay coupled with class CC current-limiting response provides close sizing on small motor and relay circuits and maximum component short circuit current rating protection
200 kA interrupt rating provides high ratings for control circuit locations
Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
Inventory consolidation of 13/32 x 1-1/2 in supplementary fuses reduces SKU investment and minimizes potential for misapplying fuse
Selective co-ordination ratio of 2:1 (within Low-Peak™ fuse family) prevents electrical shutdowns from extending beyond the failed circuit
Finger safe design with the Bussmann series class CF CUBE fuse

Specifications

Amperage Rating:	15 A
Body Size:	13/32 in Dia x 1-1/2 in L
Body Type:	Cylindrical
Class:	CC
Color:	Yellow
Country of Origin:	MX
Element:	Dual
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	20/200 kA
Material:	Melamine
Mounting Type:	Holder
Rejection/Non-Rejection:	Rejection
Response Time:	12 s at 200%
Series:	LP-CC
Terminal Type:	Ferrule
Voltage Rating:	600 VAC/150 VDC
