LP-CC-3 BSF

Name: LP-CC-3 BSF
Brand: Bussmann
SKU: LP-CC-3 BSF
Price: 73.37 USD
Availability: InStock

Bussmann Low-Peak™ LP-CC-3 Current Limiting Time Delay Fuse, 3 A, 600 VAC/150 VDC, 20/200 kA Interrupt, CC Class, Cartridge Body

Manufacturer: Bussmann

Manufacturer part number: LP-CC-3

Availability: Expected Leadtime 7 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	12
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...

$73.37

Qty:

Product Details

Brand Name

Bussmann

Type

Current Limiting

Alternate Supplier #

Grainger - 1CX55
Fastenal - 0761238

Description

Bussmann's Class CC fuses set the standard in Class CC fuse performance in the industry. Recognized for their superior performance, Bussmann has the right product for your circuit and equipment protection needs. These branch circuit rated, 600v, 200,000a IR fuses offer exceptional protection in the smallest package of any UL class of fuses. Choose from the ultimate protection provided by our Low Peak LP-CC fuses, the time delay of our FNQ-R's for your control transformer and similar control applications or the fast acting protection of our KTK-R Limitron fuses for specialized circuits such as lighting protection

Bussmann Low-Peak™ Time Delay Fuse, Current Limiting, Series: LP-CC, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 3 A, 600 VAC/150 VDC, 20/200 kA Interrupt, Class: CC, 12 s at 200% Response, Ferrule Terminal, Holder Mount, Cartridge Body Type, Dual Element, Melamine, 13/32 in Dia x 1-1/2 in L Body Size

Application

Branch Circuits, Specialized Circuits, Industrial Control and Street Lighting Applications, Safety and Security Systems

Standards

Features

200 kA interrupting rating complies with NEC section 110.9 for today's large capacity systems
Fast short circuit protection and dual element, time delay performance provide ultimate protection
Reduces existing fuse inventory by up to 33% when upgrading to Low-Peak™ fuses
Consistent 2:1 ampacity ratios for all Low-Peak™ fuses make selective co-ordination easy
Time delay characteristic avoids unwanted fuse openings from surge currents while fast response speed under short circuit conditions provides a high degree of current limitation
Current limitation protects downstream components against damaging thermal and magnetic effects of short circuit currents
A superior, all purpose, space saving branch circuit fuse that meets most protection requirements up to 30 A
Very compact, with a physical size only 13/32 x 1-1/2 in with rejection tip
Proper sizing can provide "no damage" type 2 motor starter protection for NEMA® and IEC® motor controllers
Can be used where either a time delay or a fast acting fuse is needed, making selection easier and reducing spare fuse inventories for substantial cost reduction
Superior protection for small horsepower motor circuit
12 s minimum at 200% of rated current response time
200 kA at 600 VAC rms symmetrical, 20 kA at 150 VDC interrupt rating

Specifications

Amperage Rating:	3 A
Body Size:	13/32 in Dia x 1-1/2 in L
Body Type:	Cartridge
Class:	CC
Color:	Yellow
Country of Origin:	MX
Element:	Dual
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	20/200 kA
Material:	Melamine
Mounting Type:	Holder
Rejection/Non-Rejection:	Rejection
Response Time:	12 s at 200%
Series:	LP-CC
Terminal Type:	Ferrule
Voltage Rating:	600 VAC/150 VDC
