M300299 FER

Name: M300299 FER
Brand: Mersen
SKU: M300299 FER
Price: 338.74 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Mersen

Manufacturer part number:

M300299

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

$338.74 / EA

Description

Brand Name

Mersen

Type

Size 31 High Speed

Description

Mersen, M300299, Fuse, Size 31 High Speed, Series: Protistor, Indicating, 160 A, 690 VAC, 200 kA Interrupt, Class: URD/aR, 50 Hz Frequency, End Contact with Threaded Holes Terminal, Bolted Mounting, Square Body, Ceramic, 1.99 in L x 2.01 in W x 2.22 in H Body

Application

For Protection of inverters, motor drives, UPS systems and similar 690 V or less equipments

Standards

IEC 60269.4 Compliance | UL/CSA Recognized E76491 | CCC GB 1539.4

Features

Provide maximum flexibility in equipment design and ultimate protection for today's power conversion equipment
These aR ultra-fast acting square body fuse-links are available in different body sizes, each size having multiple worldwide acceptable mounting styles
The Protistor have been engineered to provide state-of-the-art protection for semiconductors diodes, thyristors and IGBT devices
Fuses are assembled with die-cut elements embedded in solidified sand, which helps control arcing characteristics for a lower I2t and high interrupting rating level
All contact surfaces are silver plated and all hardware is non-magnetic
Each fuse-link can be equipped with a low voltage trip-indicator which can operate a field mountable microswitch
Multiple body sizes and terminals or blades combination
Very low I2t for improved semiconductor protection
Ultra fast acting
Current limiting
Superior cycling capability

Specifications

Amperage Rating:	160 A
Body Size:	1.99 in L x 2.01 in W x 2.22 in H
Body Type:	Square
Class:	URD/aR
Country of Origin:	FR
Frequency Rating:	50 Hz
Indicating/Non-Indicating:	Indicating
Interrupt Rating:	200 kA
Material:	Ceramic
Mounting Type:	Bolted
Series:	Protistor
Terminal Type:	End Contact with Threaded Holes
Voltage Rating:	690 VAC
