PDBFS377 BSF

Name: PDBFS377 BSF
Brand: Bussmann
SKU: PDBFS377 BSF
Price: 211.51 USD
Availability: InStock

Bussmann PDBFS377 Enclosed High SCCR Power Distribution Block, 600 VAC/VDC, 570 A, 1 Pole, 4 AWG to 300 kcmil Wire, Aluminum

Manufacturer: Bussmann

Manufacturer part number: PDBFS377

Availability: Expected Leadtime 7 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	5	26
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...

$211.51

Qty:

Product Details

Brand Name

Bussmann

Type

Enclosed High SCCR

Description

EATON Bussmann series finger safe power distribution block (PDBFS) with short circuit current ratings (SCCRs) up to 200 kA help achieve compliance with NEC and OSHA requirements by resolving common SCCR weak links in industrial control panels.

Bussmann Power Distribution Block, Enclosed High SCCR, Series: PDBFS, 600 VAC/VDC, 570 A, 1 Pole, 2 Primary Connections/Pole, 12 Secondary Connection/Pole, 4 AWG to 300 kcmil Wire, 100/200 kA Short Circuit Current Rating, Aluminum, Tin Plated, 4.665 in L x 1.875 in W x 2.933 in H

Application

Electrical Assemblies, Panels and EOEMs Applications

Standards

Features

4 AWG to 300 kcmil line side, 14 to 4 AWG load side wire
Meets wireway application requirements
Dual wire rated ports and the ability to use UL listed ferrules greatly expand application flexibility
DIN rail and panel mount versatility allows one product to be used for multiple applications without incurring additional inventory cost
IP20 finger safe

Specifications

Amperage Rating:	570 A
Country of Origin:	MX
Dimensions:	4.66 in L x 1.875 in W x 2.93 in H
Finish:	Tin Plated
Fuse Type:	Class LPJ/LPN-RK/LPS-RK/FRN-R/FRS-R/JJN/JJS/SC/LP-CC/FNQ-R/KTK-R
Material:	Aluminum
Number of Poles:	1
Primary Connections/Pole:	1
Secondary Connection/Pole:	12
Series:	PDBFS
Short Circuit Current Rating:	100/200 kA
Voltage Rating:	600 VAC/VDC
Wire Size:	4 AWG to 300 kcmil
