SF 2 MSG

Name: SF 2 MSG
Brand: Martin Sprocket & Gear
SKU: SF 2 MSG
Price: 61.61 USD
Availability: InStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Martin Sprocket & Gear

Manufacturer part number:

SF 2

CBT Inventory

Vendor Inventory

Availability:

6 in stock

Estimated dates are contingent upon manufacturer stock.

$61.61 / EA

Description

Brand Name

Martin

Type

Standard

Description

QD (quick detachable) bushings are designed for conventional mounting or reverse mounting. These bushings have a flange.

Martin QD Bushing, Standard, 2 in Bore Dia, 3-1/8 in Barrel Dia, 5-1/2 in Hub Dia, 3-7/8 in Bolt Circle, 4-5/8 in Flange Dia, 0.563 in Flange Thickness, 3 Bolt Holes, 3/8-16 x 2 in Screw, 11000 in-lb, 2.063 in Overall Length, 1/4 x 1/2 in Keyway, Steel

Features

Size SF bushing
QD (quick detachable) bushings are designed for conventional mounting or reverse mounting
These bushings have a flange
Precise machining and processes ensure consistent finish and high quality
Interchangeable with other manufacturersâ€™ QD bushings

Specifications

Barrel Diameter:	3-1/8 in
Bolt Circle Diameter:	3-7/8 in
Bore Diameter:	2 in
Country of Origin:	US
Flange Diameter:	4-5/8 in
Flange Thickness:	0.563 in
Hub Diameter:	5-1/2 in
Keyway Size:	1/4 x 1/2 in
Material:	Steel
Number of Bolt Holes:	3
Overall Length:	2.063 in
Screw Size:	3/8-16 x 2 in
Torque Rating:	11000 in-lb
