UCP207-23 TKN

Name: UCP207-23 TKN
Brand: Timken
SKU: UCP207-23 TKN
Price: 114.15 USD
Availability: OutOfStock

Timken® UCP207-23 UCP200 Industrial Duty Single Row Standard Pillow Block Ball Bearing Unit, 1-7/16 in Dia Bore, 21/23 in L Bolt Center-to-Center, 1-7/8 in Base to Bore Centerline, 6-9/16 in OAL x 3-3/4 in OAH

Manufacturer: Timken

Manufacturer part number: UCP207-23

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$114.15

Qty:

Product Details

Brand Name

Timken®

Type

Industrial Duty Single Row Standard

Description

Timken® U series UCP 200 mounted ball bearings (housed units) feature Timken® U Series set screw locking (UC) style wide inner ring ball bearings, contact nitrile seal and an external flinger to provide multiple levels of protection against contamination. Timken® ball bearings are ideal for handling high speeds and light radial loads.

Timken®, UCP207-23, Pillow Block Ball Bearing Unit, Industrial Duty Single Row Standard, Series: UCP200, 1-7/16 in Bore, 21/23 in Bolt Center-to-Center Length, 1-7/8 in Base to Bore Centerline, 6-9/16 in Overall Length, 1-15/16 in Overall Width, 3-3/4 in Overall Height, Two-Bolt Base Mounting, Cylindrical Bore, 1-7/8 in Base Width, Set Screw Locking Device, Triple Lip Seal, Non-Expansion, 25.7 lb Dynamic/15.4 lb Static Load, -4 to 212 deg F, 3700 rpm Maximum, Cast Iron, Powder Coated

Application

Materials Handling, Food, Beverage, Agriculture, Packaging, Industrial Fans/Blowers, Glass Making, Brick Making, Paper and Printing Industries

Features

UCP pillow blocks are suggested for industrial applications where normal loads are encountered
Compact, 1-piece housing with 2-bolt mounting can be installed in any position and makes bearing replacement easy
These units use wide inner ring ball bearings with self aligning spherical outside diameters that compensate for shaft misalignment
Timken® UCP series housed units feature the Timken® set screw locking (UC) bearing insert
Bearing prelubricated and ready for immediate installation
Grease fitting supplied for relubrication
The bonded seal design is well suited for applications involving wet or dirty environments
Bolt hole spacing dimensions and shaft center location are interchangeable with competitive units
Housing designed for ease of bearing replacement
Provides the first level of protection against contamination
Bonded nitrile rubber seal with an engineered interface to the inner ring
Helps protect against abrasive wear, extending seal life
Engineered fit between bearing and housing to improve bearing life
Precision machined lubrication groove and holes in the outer ring of the bearing
Steel cage provides effective ball guidance and high temperature service capability
Improved shaft support over narrow rings, improving bearing life and reducing misalignment
120 deg angle minimizes inner ring distortion for smoother running bearing
Prelubricated with high-quality lithium-based grease, compatible with most industrial greases
Spherical outer diameter
CN internal clearance

Specifications

Base to Bore Centerline:	1-7/8 in
Base Width:	1-7/8 in
Bolt Center-to-Center Length:	21/23 in
Bore Diameter:	1-7/16 in
Bore Type:	Cylindrical
Expansion Type:	Non-Expansion
Finish:	Powder Coated
Load Capacity:	25.7 lb Dynamic/15.4 lb Static
Locking Device:	Set Screw
Material:	Cast Iron
Maximum Speed:	3700 rpm
Mounting Type:	Two-Bolt Base
Overall Height:	3-3/4 in
Overall Length:	6-9/16 in
Overall Width:	1-15/16 in
Seal Type:	Triple Lip
Series:	UCP200
Temperature Rating:	-4 to 212 deg F
