Actual Product May Vary From Image

UGB2/0-414-6 PAN

Name: UGB2/0-414-6 PAN
Brand: Panduit
SKU: UGB2/0-414-6 PAN
Price: 53.32 USD
Availability: OutOfStock

Panduit® StructuredGround® UGB2/0-414-6 6-Port Universal Grounding Bar, 4.92 in L x 0.62 in W x 0.48 in H

Manufacturer: Panduit

Manufacturer part number: UGB2/0-414-6

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$53.32

Qty:

Product Details

Brand Name

Panduit®

Type

6-Port Universal

Description

The patented StructuredGround® universal ground bar system (UGB) offer multiple termination method and mounting option making It ideal for any control panel or enclosure application. The UGB enable the end user to choose the method in which to terminate conductor with connector of their choice or simply cut and strip the wire. The UGB system will help reduce the type of ground bar that a panel shop or distributor need to keep in stock to meet the various application and customer requirement.

Panduit® StructuredGround® Grounding Bar, 6-Port Universal, 0.62 in Bar Width, 4.92 in Bar Length, 0.48 in Bar Height, Lug Connection, 2/0 AWG Cable Main, Copper, Electrolytic/TiN Coated

Application

Utility/Ground Grid Applications

Standards

ARRA Compliant | Buy American Act Compliant | CSA 22.2 | RoHS Compliant | UL 467/508A

Features

Universal ground bar accepts 14 to 4 AWG wire in 6 wire ports and up to a 2/0 AWG main equipment grounding conductor with a compression or mechanical connector
Flexible design works with all types of wire termination methods including stripped wire, ferrules, terminals and compression or mechanical connectors compatible with over 140 Panduit® connectors
Unique geometry the unique shape of the universal ground bar allows more surface contact between the wire connectors and the ground bar

Specifications

Bar Height:	0.48 in
Bar Length:	4.92 in
Bar Width:	0.62 in
Cable Main:	2/0 AWG
Cable Tap:	14 to 4 AWG
Connection Type:	Lug
Country of Origin:	MX
Finish:	Electrolytic/TiN Coated
Material:	Copper
